Product Code:
CP-237
Weight:
65.00g
Dimensions:
100.00mm x 12.00mm x 71.00mm
Custom Field 1 (UPC):
Protected Link
CP-237 Power Supply 24 VDC
NX I/O power feed unit, 5-24 V DC input, 8 terminals, 4A, screwless push-in connector, 12mm wide
NX-PF0630
| I/O system | NX I/O Bus |
| Type of module | Power feed |
| I/O connection type | Push-in |
| Number of I/O connectors | 1 |
| Detachable I/O connector | |
| Suitable for safety functions | |
| SIL according to IEC 61508 | None |
| Number of IOV (V+) terminals | 4 |
| Number of IOG (V-) terminals | 4 |
| Number of FG terminals | 0 |
| Degree of protection (IP) | IP20 |
| Height | 100 mm |
| Width | 12 mm |
| Depth | 71 mm |
| Weight | 65 g |
810 Ref PF 0630
812 Ref PF 0630
| Spare Part Type | |
|---|---|
| Electrical Component | |
| Stock Type | |
| Standard Stock | |
